2014 Ford Mustang Tune Up: Spark Plugs, Ignition Coils, and Upper Intake Gasket Done Right
A 2014 Ford Mustang V6 with the 3.7 Cyclone engine landed on our schedule for a full tune up. The customer was just over 120,000 miles and, believe it or not, this was the first time the spark plugs and ignition coils were being replaced.
There were a few minor concerns going into the visit, including a previous EVAP small leak code that had triggered a check engine light. By the time we arrived, the light had already cleared itself. We came prepared with a purge valve just in case, but the customer decided to hold off unless the code comes back.
With that aside, the focus of the visit was straightforward maintenance: spark plugs, ignition coils, and replacing the upper intake manifold gasket while everything was apart.
This is one of those jobs that doesn’t always feel urgent, but makes a huge difference in how the car runs once it’s done.
Why Tune Ups Matter More After 100K Miles
Modern engines can go a long time without major service, but that doesn’t mean they should.
Spark plugs and ignition coils wear gradually over time. You may not notice the performance drop right away, but it shows up in small ways: slightly rough starts, reduced fuel efficiency, minor hesitation, or less responsive acceleration.
At around 100,000 to 120,000 miles, these components are usually well past their prime.
In this Mustang’s case, the original Motorcraft plugs had done their job, but they were due. Waiting longer increases the risk of seized plugs or damaged porcelain during removal, which can turn a simple job into a much bigger one.
Why We Replace the Upper Intake Gasket at the Same Time
On the 3.7 Cyclone engine, accessing the spark plugs requires removing the upper intake manifold.
Any time that manifold comes off, the gasket should be replaced.
It’s a relatively inexpensive part, but it plays a critical role in sealing the intake system. Reusing an old gasket can lead to vacuum leaks, rough idle, or even check engine lights down the road.
Since the labor to access it is already done during a tune up, replacing it at the same time is the smart move.
What We Installed
For this Mustang, we went with a full set of double platinum spark plugs and brand new ignition coils.
Ford recommends double platinum plugs for this engine, and we opted for a high-quality set to ensure long-term reliability.
The ignition coils were replaced as preventative maintenance. While not all coils fail at the same time, replacing them together ensures consistent performance across all cylinders and reduces the chance of a misfire later on.
What We Found During the Job
Overall, the vehicle was in great condition for its mileage.
The engine bay was clean, and it was clear the owner takes good care of the car. The only minor issue we noticed was a small amount of oil residue around the cam sensors, which is common on these engines.
In most cases, that comes from aging valve cover seals. It’s not an urgent issue, but something to keep an eye on over time. Fixing it properly usually means replacing the valve covers, which isn’t always necessary unless the leak gets worse.
Other than that, everything checked out solid.
The Repair Process
This tune up follows a clean and methodical process:
- Remove engine cover and disconnect intake components
- Remove the upper intake manifold
- Inspect and clean mating surfaces
- Remove old ignition coils
- Remove old spark plugs carefully to avoid damage
- Install new double platinum spark plugs
- Install new ignition coils
- Replace upper intake manifold gasket
- Reinstall intake manifold and all components
- Double-check connections and wiring
- Start the vehicle and verify smooth operation
The job requires attention to detail, especially when routing wiring and ensuring nothing gets pinched during reassembly.
The Result
Once everything was buttoned up, the difference was immediate.
The engine fired up smoothly, with a noticeably cleaner idle. Any slight hesitation or roughness was gone, and the engine felt more responsive overall.
This is exactly what a proper tune up should do: restore performance, improve efficiency, and give the engine a fresh baseline moving forward.
Mobile Service Makes Jobs Like This Easy
A job like this usually means dropping your car off at a shop for half a day or more.
With Johnny On The Go Auto Care, it happens right in your driveway.
The customer didn’t have to rearrange their schedule, wait in a lobby, or worry about transportation. We handled everything on-site, from teardown to final startup.
Signs Your Vehicle Might Need a Tune Up
If your car is showing any of these signs, it may be time:
Rough idle or shaking at stops
Slower acceleration than usual
Decreased fuel efficiency
Engine hesitation
Misfire or check engine light
Hard starts, especially in colder weather
Even if the symptoms are minor, staying ahead of maintenance keeps small issues from turning into bigger ones.
